Adjustable-Leg Reach Stacker
1.4T
Noblelift model ref: XWS-140
- Capacity
- 1,400 kg
- Power
- Lead-acid or lithium-ion, 24 V
- Use
- Indoor, mixed pallet widths
- Lift height
- 4,800 mm
- Turning radius
- 1,595 mm
Prefer email? info@pristinemh.com · Mon–Fri, 8am–4pm
See the Pedestrian Reach range · Mast, battery and attachments are confirmed when we quote.
- 12-month parts and labour warranty as standard
- Finance through funding partners, subject to status
- Part-exchange of your existing equipment
- Delivery, handover and operator familiarisation
About the Adjustable-Leg Reach Stacker
The Adjustable-Leg Reach Stacker (Noblelift XWS-140) is a walk-behind stacker from our Pedestrian Reach line, with a reach function for placing pallets into racking. The distance between its wheel arms adjusts, so one truck can handle mixed pallet widths. Send us your pallet widths and narrowest aisle, and we'll confirm the wheel-arm setting and aisle fit.
Specifications
Noblelift's figures for each model in the range. Your quotation includes the full specification sheet for the build you choose.
| Model | XWS-140 | XWS-140 |
|---|---|---|
| Load capacity (kg / lb) | 1400 | 3000 |
| Load centre (mm / in) | 600 | 24 |
| Lift height (mm / in) | 4800 | 189 |
| Distance between wheel arms, adjustable (mm / in) | 860 / 960 / 1060 / 1260 | 34 / 38 / 42 / 46 / 50 |
| Reach distance (mm / in) | 575 | 23 |
| Aisle width, 1000 × 1200 lengthways (mm / in) | 2616 | 95.13 |
| Turning radius (mm / in) | 1595 | 62.8 |
| Gradeability, laden / unladen (%) | 8 / 12 | 8 / 12 |
| Battery voltage / capacity (V / Ah) | 24 / 200 (Li-ion) | 24 / 360 (Lead acid) |
